Description
SPECIFICATIONS
| Output frequency
Output Mode Pulse Ratio Power Level |
1MHz
Continuous & Pulse 1:1,1:2, 1:4, 1:7,1:8 & 1:16 0.1 to 3.1 watts/cm2 |
| Carrier
Modes Base Sweep Output Intensity |
2, 3, 4, 5, and 6 KHz
4P,4PV-2PL,4PV-LIN,4PV-TRP, 4PV-NL,2P and Russian Current 0-150 Hz adjustable 0-150 Hz adjustable with Linear pattern 0-99mA adjustable |
| Modes
Faradic Surge Faradic Interrupted Galvanic Output Intensity |
Faradic, Surge Faradic, Galvanic and Interrupted Galvanic
0.7mS ON time @20mS period Hold:3 sec & Rest:2 sec ON time:100ms Rest time: 3 sec 0-99mA adjustable |
| Channels
Mode Frequency Burst period Output |
Two
Continuous & Burst up to 150 Hz @ 400µs pulse width @ Hold:3 sec & Rest:2 sec 0 – 65mA adjustable and isolated |
| Input Power | SMPS @ 100V – 275V AC, 50Hz Operated |
| Dimension | 390x 220 x 95 mm |
| Weight | 3 kg |
