Description
SPECIFICATIONS
Frequency | 2, 3, 4, 5 and 6 KHz |
Base | 1 to 150Hz @ 1 Hz step |
Spectrum | 1 to 150Hz @ 1 Hz step with Linear, Non-Linear and Trapezoidal shape |
Mode | 4P, 4PV, 2P and Russian Current |
Vector type | 2PL, 4PL, 4PT & 4PNL |
Output Isolated | 0 – 100V |
Timer | 1 – 30 minutes adjustable |
Input Power | SMPS @ 100V – 275V AC, 50 Hz Operated |
Dimension | 185 x 205 x 90 mm |
Weight | 2 kg |
