Description
SPECIFICATIONS
| Therapy Modes | Faradic, Surge Faradic, Galvanic, Interrupted Galvanic & TENS |
| TENS | |
| Mode
Frequency Burst period Output |
Continuous & Burst
up to 150 Hz @ 400 µs ON time Hold & Rest @ 1-6 sec adjustable 0 – 65 mA |
| Stimulator | |
| Faradic
Surge Faradic Interrupted Galvanic Output Intensity |
0.7mS ON time @20mS period
Faradic @ Hold:1 to 6 sec & Rest:2 sec ON time :0.01 to 1000 ms adjustable, Rest time: 3 sec 0 – 65mA adjustable |
| Power Supply | LPS @ 230VAC, 50Hz |
| Dimension | 165 x 165 x 75 mm |
| Weight | 1.70 Kg |
