Semi Digital IFT is the next segment machine to the conventional analog machine which comes with an advanced micro controller to manage entire operation like power amplifier drive, timer, intensity control/indication and modes of the machine hence brings accuracy in its performance. Traditional potentiometer & rotator knobs are replaced with feather touch keys, LED bar graph and seven segment displays.
| Medium Frequency | 2, 3, 4, 5, 6 KHz and Russian Current |
| Base | up to 150Hz |
| Spectrum | up to 100Hz with Linear, Non-Linear and Trapezoidal |
| Mode | 4P, 4PV, 2P |
| Vector type | Linear, Non-Linear & Trapezoidal |
| Output | Isolated 0 – 100V |
| Timer | 1 – 30 minutes adjustable |
| Input Power | SMPS @ 100V – 275V AC, 50 Hz Operated |
| Dimension | 290 x 290 x 110 mm |
| Weight | 2.6 kg |
