Description
SPECIFICATIONS
| Output frequency
Output Mode Pulse Ratio Power Level |
1MHz
Continuous & Pulse 1:1,1:2, 1:4, 1:7,1:8 & 1:16 0.1 to 3.1 watts/cm2 |
| Modes
Faradic Surge Faradic Interrupted Galvanic Output Intensity |
Faradic, Surge Faradic, Galvanic and Interrupted Galvanic
0.7mS ON time @20mS period Faradic @ Hold:3 sec & Rest:2 sec ON time:0.01 to 1000 ms adjustable Rest time: 3 sec 0-99mA adjustable |
| Channels
Mode Frequency Burst period Output |
Two
Continuous & Burst up to 150 Hz @ 400µs pulse width @ Hold:3 sec & Rest:2 sec 0 – 65mA adjustable and isolated |
| Timer | 1 – 30 minutes adjustable for treatment time control |
| Input Power | SMPS @ 100V – 275V AC, 50 Hz Operated |
| Dimension | 313 x 220 x 95 mm |
| Weight | 2.7 kg |
